Thông tin chi tiết sản phẩm:
|
| Ứng dụng: | Sự thi công | Chiều rộng: | 1000-2000mm |
|---|---|---|---|
| Loại: | Tấm, tấm thép không gỉ | Tiêu chuẩn: | ASTM,JIS,AISI,EN |
| Chiều dài: | Yêu cầu của khách hàng, 1000-6000mm hoặc Yêu cầu của khách hàng | Thể loại: | Dòng 300 |
| Tên sản phẩm: | ASTM JIS SUS 201 202 301 304 304l 316 316l 310Tấm thép không gỉ | Bề mặt: | BA/2B/SỐ 1/SỐ 3/SỐ 4/8K/HL/2D/1D |
| Độ dày: | 0,2-60mm | Bờ rìa: | Cạnh khe, cạnh Mill |
| Kỹ thuật: | Kết thúc cán nguội | Thời hạn giá: | CIF CFR FOB EX WORK |
| Standard | AISI ASTM GB |
| Place of Origin | China |
| Model Number | 200 Series:201 202 |
| 300 Series:301 302 303 304 304L 309 309S 310 316 316L 321 904L 316LVM | |
| 400 Series:410 420 430 440 | |
| Duplex stainless:2205 2507 | |
| Type | Flat/corrugated/checkered |
| Processing Service | Bending,Welding,Decoiling,Punching,Cutting, Moulding |
| Surface Finish | 2B/No.1/Mirror Finish/Satin Polished |
| Delivery Time | 3-10 days |
| Payment terms | 30%TT Advance+70% Balance against the copy of bill of loading |
| Sample | Sample Avaliable |
| Inspection | Accept Thrid Party Inspection |
| Thickness | 0.3mm-100mm |
| Port | Tianjin Shanghai Qingdao |
| Certification | ISO9001 |
| Packing | Standardsea worthy export packing or according to the customers' request. |
| Applications: | Kitchenware,home appliances,construction decoration,stairs,refrigerated container,burner parts,exhaust parts of auto |
| Container Size: | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)24-26CBM |
| Product Name | ASTM F138 316LVM S31673 X2CrNiMo18-15-3 1.4441 Stainless Steel Medical Sheet for Surgical implantation |
| Standard | ASTM F139,ASTM F138 |
| Diameter | 0.3mm - 30 mm |
| Length | As requirement |
| Finish | Black, Peeled, Polishing, Bright 2B |
| Technical | Hot rolled, cold drawn, forged |
| MOQ | 1Ton |
| Certification | ISO 9001:2008 , MTC , PMI , CO , SGS |
| Shape | stainless steel Flat round, square, rectangular, bending |
Stainless steel 316LS/ 316LVM or AISI 316LS/AISI 316LVM, also known as "medical grade" stainless steel, is an electro-slag remelted (ESR) or vacuum arc-remelted (VAR), low carbon, high nickel and molybdenum version of 316L stainless. The process of Vacuum melting is to achieve the extremely high level of purity and "cleanliness" required for surgical implants. The alloy has good mechanical properties and corrosion resistance, excellent resistance to physiological environment, general corrosion and intergranular corrosion, pitting corrosion and crevice corrosion, and is widely used in medical implants such as fracture fixation devices, bone plates, screws, intramedullary nails, surgical implant devices, surgical instruments
| C | Ni | Mo | Cr | Si | Mn | P | S | N | Cu |
| 0.03 | 13-15 | 2.25 - 3 | 17- 19 | 0.75 | 2.0 | 0.025 | 0.01 | 0.10 | 0.50 |
| % Cold Worked | 0.2% Yield Strength | Ultimate Tensile Strength | % Elongation in 4D |
| 35 | 793 | 862 | 18 |
| 48 | 827 | 1000 | 16 |
| 52 | 848 | 1034 | 16 |
| 60 | 883 | 1103 | 16 |
| 70 | 896 | 1172 | 15 |
| 80 | 945 | 1241 | 13 |
| Stainless steel grade and chemical composition(%) |
| Grade | C | Si | Mn | P ≤ | S ≤ | Cr | Ni | Mo | N |
| 201 | ≤0.15 | ≤1.00 | 5.5-7.5 | 0.06 | 0.03 | 16-18 | 3.5-5.5 | - | ≤0.25 |
| 202 | ≤0.15 | ≤1.00 | 7.5-10.0 | 0.06 | 0.03 | 17-19 | 4-6 | - | ≤0.25 |
| 301 | ≤0.15 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | 6-8 | - | ≤0.10 |
| 304 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | 8-10.5 | - | - |
| 304L | ≤0.03 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | 8-12 | - | - |
| 309 | ≤0.2 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 22-24 | 12-15 | - | - |
| 309S | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 22-24 | 12-15 | - | - |
| 310 | ≤0.25 | ≤1.50 | ≤2.00 | 0.045 | 0.03 | 24-26 | 19-22 | - | - |
| 310S | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 24-26 | 19-22 | - | - |
| 316 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | 10-14 | 2-3 | - |
| 316L | ≤0.03 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | 10-14 | 2-3 | - |
| 316H | 0.04-0.1 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | 10-14 | 2-3 | - |
| 316Ti | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 16-18 | 10-14 | 2-3 | ≤0.10 |
| 317 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | 11-15 | 3-4 | - |
| 317L | ≤0.03 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 18-20 | 11-15 | 3-4 | - |
| 321 | ≤0.08 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 17-19 | 9-12 | - | ≤0.10 |
| 321H | 0.04-0.1 | ≤1.00 | ≤2.00 | 0.045 | 0.03 | 17-19 | 9-12 | - | ≤0.10 |
| 409 | ≤0.08 | ≤1.00 | ≤1.00 | 0.045 | 0.03 | 10.5-11.7 | ≤0.50 | - | - |
| 410 | ≤0.15 | ≤1.00 | ≤1.00 | 0.04 | 0.03 | 11.5-13.5 | ( ≤0.75) | ||
| 420 | ≥0.15 | ≤1.00 | ≤1.00 | 0.04 | 0.03 | 12-14 | - | - | - |
| 430 | ≤0.12 | ≤1.00 | ≤1.00 | 0.04 | 0.03 | 16-18 | - | - | - |
| 2507(Cu ≤0.5) | ≤0.03 | ≤0.8 | ≤1.2 | 0.035 | 0.02 | 24-26 | 6-8 | 3-5 | 0.24-0.32 |
